5094-IM8 and 5094-IM8XT Digital 8-channel 240V AC Input Modules
This figure shows a wiring diagram for the 5094-IM8 and 5094-IM8XT modules. You must connect a 240V AC power source to the left L1 and
L2 terminals to provide field-side power.
5094-IM8 and 5094-IM8XT Wiring Diagram
